High-Speed, Clean Finish & Intelligent Control

• Direct-drive motor: mounted directly to the main shaft for fast response, smooth acceleration and low vibration.
• Needle positioner: automatically stops the needle up or down, making it easier to pivot fabric, align corners and restart seams.
• Automatic thread trimmer: activate with a back-kick on the pedal—the machine cuts the thread automatically at the end of the seam, reducing manual trimming.
• Integrated LED light: bright, focused lighting directly over the needle area for better visibility on dark fabrics and detailed work.
• High-speed straight stitch: ideal for everyday sewing on light to medium fabrics with professional stitch quality.

Materials & Applications

Designed for light to medium-weight fabrics, the SW-8700C is perfect for:

1. Garment production – shirts, blouses, pants, dresses, uniforms, kidswear.
2. Alterations & tailoring – hemming, repairs, taking in/letting out garments.
3. Light home décor – curtains, pillow covers, simple cushion covers.
4. Uniforms & workwear – seams on twill, poplin, poly-cotton and similar fabrics within its range.

If you need a fast, clean, reliable straight-stitch machine with direct drive, thread trimming and needle positioning, this is the ideal setup.

Key Features

• Single needle industrial lockstitch machine
• Direct-drive motor integrated on the head (no belt)
• Needle positioner – automatic up/down stop
• Automatic thread trimmer – activated by back-kicking the pedal
• Integrated LED light on the sewing area
• Based on the proven SPEEDWAY SW8700D platform, upgraded with full electronic features
• High-speed operation for efficient production on light/medium fabrics
• Industrial table & stand with wheels for easy mobility and repositioning in the shop
• Automatic lubrication for long service life
• Adjustable stitch length for general garment construction
• Reverse lever for easy backtacking at the start and end of seams

Technical Specifications (typical configuration)

• Model: SPEEDWAY SW-8700C
• Stitch Type: Single-needle lockstitch
• Motor Type: Integrated direct-drive (with needle positioner)
• Max Sewing Speed: up to approx. 4,500–5,000 stitches per minute (depending on material and setup)
• Stitch Length: 0–5 mm (adjustable)
• Feed System: Drop feed
• Needle System: DBx1 (sizes approx. #9–#18 depending on fabric and thread)
• Presser Foot Lift:
• By hand: approx. 5.5 mm
• By knee: up to approx. 13 mm
• Lubrication: Automatic (central oil system)
• Lighting: Integrated LED work light
• Stand: Industrial stand with wheels for easy movement

(Exact speed and parameters may vary slightly depending on final setup and region.)

What’s Included

• SPEEDWAY SW-8700C sewing machine head with direct-drive motor, needle positioner and thread trimmer
• Industrial table & stand with wheels, fully assembled
• Built-in bobbin winder and thread stand
• Standard presser foot, needles, bobbins, oil and basic tool kit (may vary slightly by batch)
