High-Speed, Reliable & Affordable

• 550W servo motor (belt-driven) provides quiet operation, low energy consumption and excellent speed control.
• High-speed operation up to 5,500 SPM for serious production on garments and light home textiles.
• Classic 8700-style platform that operators know and trust—easy to learn, easy to maintain.
• Built with Speedway’s robust standards, offering long service life and stable stitch quality at an accessible price point.

Materials & Applications

The SPEEDWAY SW-8700 is designed for light to medium-weight fabrics, making it a perfect all-rounder for:

1. Garment manufacturing – shirts, blouses, trousers, dresses, uniforms, casualwear.
2. Alteration shops & tailors – hemming, seam repairs, basic tailoring and adjustments.
3. Light home décor – curtains, pillow covers, lightweight cushion covers.
4. Uniforms & workwear (light/medium) – poly-cotton, poplin, twill and similar fabrics within its range.

If you’re looking for a straightforward, high-speed straight-stitch machine similar to the classic DDL-8700 style at a more accessible price, the SW-8700 is the right choice.

Key Features

• Single needle lockstitch industrial sewing machine
• 550W servo motor, belt-driven (quiet, energy-efficient, smooth control)
• High-speed sewing up to 5,500 SPM
• Designed for light to medium-weight fabrics
• Adjustable stitch length for general garment construction
• Reverse lever for easy backtacking at seam start/end
• Automatic lubrication system for reduced maintenance and longer life
• Simple mechanical controls, easy for operators of all levels
• Industrial table & stand included, pre-assembled for plug-and-sew setup

Technical Specifications (typical configuration)

• Model: SPEEDWAY SW-8700
• Stitch Type: Single-needle lockstitch
• Motor Type: 550W servo motor, belt-driven
• Max Sewing Speed: up to 5,500 stitches per minute
• Stitch Length: 0–5 mm (adjustable)
• Feed System: Drop feed
• Needle System: DBx1 (typical sizes #9–#18 depending on fabric and thread)
• Presser Foot Lift:
• By hand: approx. 5.5 mm
• By knee: up to approx. 13 mm
• Lubrication: Automatic (central oil system)
• Application: Light to medium woven and some light knits, depending on setup

(Exact parameters may vary slightly depending on configuration and region.)

What’s Included

• SPEEDWAY SW-8700 sewing machine head
• 550W servo motor (mounted and belt-installed)
• Industrial table & stand, assembled
• Built-in bobbin winder and thread stand
• Standard presser foot, needles, bobbins, oil and basic tool kit (may vary slightly by batch)
